Lab Equipment

Keysight DSOX1204G

Oscilloscope

4-channel oscilloscope with an integrated waveform generator.

Teledyne LeCroy T3DSO-HD

Oscilloscope

12-bit high-definition oscilloscope.

Stanford Research Systems DS360

Function Generator

Ultra-low distortion generator (DC – 200 kHz) for high-fidelity analog test signals.

Siglent SVA1075X

Spectrum / Network Analyzer

Combined spectrum and vector network analyzer covering 9 kHz – 7.5 GHz.

Rohde & Schwarz SMC100A

RF Signal Generator

Analog RF signal generator spanning 9 kHz – 3.2 GHz.

Rohde & Schwarz SMCV100B

Vector Signal Generator

Vector signal generator for modulated and multi-standard communication signals.

Keysight B2901BL

Source / Measure Unit

Precision SMU for sourcing and measurement of voltage and current.

Keysight E36312A

DC Power Supply

(2x) Triple-output programmable DC power supply with GPIB add-on.

Keysight 34450A

Digital Multimeter

5½-digit bench multimeter with a dual-display OLED readout.

Bench Supplies & Multimeters

Miscellaneous

Older general-purpose DC power supplies and digital multimeters.

Bench PC

Automation

Windows 11 with Intel i7-8700K, 16 GB RAM, 500 GB SSD, and USB-GPIB module.

Soldering & Rework Bench

Assembly & Rework

Hot-air rework station, microscope, and surface mount components for board assembly.
